Industrial Ethernet / PROFINET

Product no. L45467-J16-B26
HB Cables stock the marine approved L45467-J16-B26 in reels as small as 25m. UL/CSA, RoHS and for marine and offshore applications. Approved by Germanischer Lloyd, Lloyds Register of Shipping, ABS Europe, Bureau Veritas, Det Norske Veritas.

Enquire about this product

Application

Industrial Ethernet Cat5e ES, PROFINET flexible cable for marine applications (easy to strip, FRNC),

2x2x22AWG7,

UL listed: CMG and PLTC

Characteristics

Flame retardant acc. to IEC 60332-3-22 category A/F,

halogen free,

sunlight-resistant,

limited oil resistant,

UL-File E119100, Vol. 1, Sec. 11, Page 1,

UL-File E352715 Vol. 1 Sec. 1 Page 1 Verified CAT 5E,

UL-File E116441, Vol. 1, Sec. 6, Page 4

Maritime and offshore approvals: Germanischer Lloyd, Lloyds Register of Shipping, ABS Europe, Bureau Veritas, Det Norske Veritas

Conductor

Stranded tinned copper wire 7 × 0.25 (0.010 in), Ø 0.75 mm (0.030 in) insulation of PP Ø 1.5 mm

Core

Filler as central element, 4 wires twisted to a quad, plastic tape, opverlapped, inner jacket: FRNC

Shield

Alulaminate foil overlapped, shield braiding of tinned copper wires Ø 0.13 mm (0.005 in)

Jacket

Thermoplastic Copolymer (FRNC) green Ø 6.5 ± 0.4 mm (0.256 ± 0.016 in)

Type designation

L-9YH(ST)CH 2x2x0.34/1.5-100 GN VZN FRNC

Number of wires

4

Part number:

L45467-J16-B26
